Sometimes we want our Widget to take up all the remaining space in a Column/Row, or we may want each Widget within a Column/Row to share space equally. The two Widgets commonly used to handle these situations are undoubtedly Flexible and Expanded. So what’s the difference between them?

Flexible

Flexible is used to make a child Widget expand to fill the remaining space along the main axis (for Row this is horizontal; for Column it’s vertical), but without forcing it. This means we can still set a specific width/height for that child if desired.

The key property of Flexible is fit, which controls how the child Widget handles the available space. The fit property takes a FlexFit value, of which there are two types: FlexFit.loose and FlexFit.tight. The default is FlexFit.loose, which doesn’t force the child Widget to use all available space—it can be any size up to the maximum remaining space, or smaller.

On the other hand, FlexFit.tight forces the child Widget to use all remaining space.

Additionally, Flexible is useful when we want to divide space into different proportions using the flex property, which defaults to 1. We can set this to various numbers to create proportional calculations when used alongside other Flexible Widgets.

The flex space calculation works by taking the total available space and subtracting the space used by inflexible Widgets (those with static sizes, such as directly specified width/height). The remainder is then divided according to the proportions.

For example, if we have two Flexible Widgets—one with flex: 1 and another with flex: 2—plus a Container with width: 50 in the same Row, and our total available horizontal space is 350, the calculation proceeds as follows:

Start with 350, then subtract the main-axis size of the inflexible Widget. Here we have one Container with width: 50, leaving us with 300 to divide.

Next, we check the total flex values: flex: 1 plus flex: 2 equals 3. So 300 ÷ 3 = 100, meaning one flex unit equals 100.

We then allocate space proportionally: the Flexible with flex: 1 gets a width of 100, while the Flexible with flex: 2 gets a width of 200.

Expanded

So what about Expanded? The answer is: it’s simply Flexible with fit: FlexFit.tight. This means Expanded can do everything Flexible does, but it forces the child Widget to use all remaining available space.
